DMX2SW
Compact two-channel DMX-controlled power switch — two 8 A relays with PowerCon TRUE1 throughput.
Applications
Live eventsTheatreTouringTV / Broadcast
Features
- 2-channel relay switch, 2 × 8 A
- Secured with time-lag fuses
- Signal lamp for switching status
- Two LED indicators of DMX line status
- Compact size
- Input: NAC3PX (Neutrik PowerCon TRUE1 TOP) with THRU output
- Multiple output connector options
Specifications
Type
DMX switching unit
Channels
2 × 8 A relay
Protection
Time-lag fuses
Indicators
Signal lamp · 2× DMX status LEDs
Power input
NAC3PX (PowerCon TRUE1 TOP) + THRU
Outputs
Multiple connector options
