DMX1SW
Compact one-channel DMX-controlled power switch — 16 A relay, double-pole, with PowerCon TRUE1 throughput.
Applications
Live eventsTheatreTouringTV / Broadcast
Features
- 1-channel relay switch, 1 × 16 A
- Double pole (1P+N)
- Secured with a 16 A MCB
- Signal lamp for switching status
- Two LED indicators of DMX line status
- Compact size
- Input: NAC3PX (Neutrik PowerCon TRUE1 TOP) with THRU output
- Multiple output connector options
Specifications
Type
DMX switching unit
Channels
1 × 16 A relay
Pole
Double pole (1P+N)
Protection
MCB 16 A
Indicators
Signal lamp · 2× DMX status LEDs
Power input
NAC3PX (PowerCon TRUE1 TOP) + THRU
Outputs
Multiple connector options
