MANTIS
Versatile, tri-armed LED blinder with tungsten emulation, RGBW glow and a gobo-capable centre.
Applications
ConcertFestivalsLive eventsStage designTheatreTouring
Features
- Versatile tri-armed LED blinder with a distinctive central decorative section
- 3× 60 W portman haloLED with true tungsten emulation (1,600–3,200 K)
- 3× 12 W RGBW glow for warm punch plus full colour
- 1× 18 W RGBW central light with frosted diffuser — accepts a cut gobo
- 16-bit dimming and colour mixing; Portman Flicker Free
- Portman Colour Feedback System for consistent colour
- 250 W of LED power in an 8 kg housing, mountable in any position
Specifications
Type
Tri-arm decorative blinder
Main source
3× 60 W haloLED dim-to-warm, 1,600–3,200 K
Colour source
3× 12 W RGBW glow
Central source
1× 18 W RGBW with frosted diffuser (gobo-capable)
CRI
>90
Dimming
16-bit dimming and colour mixing
Optics
High-reflective hammered reflector
Control
6 DMX modes (21–43 ch) · DMX/RDM · optional W-DMX
Connectors
powerCON TRUE1 (AC) · 5-pin XLR (DMX in/out)
Power
max 250 W; 100–240 V, 50/60 Hz
IP rating
IP20 (indoor)
Mounting
Any position; 13 mm hole for spigot/clamp
Dimensions
650 × 650 × 170 mm
Weight
8 kg
