MAC Aura PXL
Multi-source LED wash — 10,000 lm with individual pixel control of every beam and aura LED.
Applications
ConcertFestivalsLive eventsStage designTouringTV / Broadcast
Features
- Individual pixel control of every beam (19) and aura (141) LED
- 10,000 lm RGBW solid-state mixing: vibrant saturates plus calibrated pastels and whites
- Precise, silent 1:8 zoom from tight narrow beam to wide wash
- Flicker-free LED driver suitable for all camera applications
- Variable CTC (2,000–10,000 K) with four selectable dimming curves
- Full Martin P3 video-protocol integration alongside DMX/RDM/Art-Net/sACN
- Compact, lightweight body with low-noise, output-vs-sound cooling
Specifications
Beam source
19 × 40 W RGBW LEDs (pixel-controlled)
Aura source
141 × 0.3 W RGB LEDs (pixel-controlled)
Light output
10,000 lm
Colour temperature
Variable 2,000–10,000 K (CTC)
CRI
73+
Zoom
6°–40° beam (1:8 motorised); field to 59°
Colour
RGBW; virtual colour wheel, 36 presets
Movement
Pan 540° / tilt 268° (16-bit)
Control
DMX · RDM · Art-Net · sACN · Martin P3
Power
100–240 V; powerCON TRUE1 in/out; etherCON
Ingress protection
IP20
Dimensions
410 × 232 × 516 mm (max)
Weight
15.6 kg
