THE FAB²
The hazer revolution, refined — a low-profile 19″ rack hazer with DMX air baffles and sensor control.
Applications
ConcertLive eventsStage designTheatreTouringTV / Broadcast
Features
- Directly heated 500 W evaporator in a slim, rack-friendly 19″ flightcase
- Twin motorised air baffles, DMX-controllable to “full swing,” fed by two 100 m³/h axial fans
- Innovative sensor technology for consistent, repeatable haze output
- Networked control out of the box — DMX512, RDM, sACN and Art-Net, plus JT Remote
- Ready in ~8 seconds, with haze output controllable from 1–100 %
- Runs base*V and base*B fluid from a 1-litre tank; flightcase included
Specifications
Type
Haze machine (directly heated evaporator)
Power
500 W (PowerCON TRUE1)
Warm-up time
approx. 8 seconds
Tank capacity
1,000 ml
Haze output
1–100 % controllable
Fans
2 axial, 100 m³/h each
Air baffles
2, motor-adjustable to “full swing”
Control
DMX512 · RDM · sACN · Art-Net · JT Remote
Fluids
base*V, base*B
Format
19″ flightcase included (2 HE)
Dimensions (L×W×H)
533 × 523 × 110 mm
Weight
16.6 kg
