Long-throw IP66 LED profile moving head — 21,000 lm and a 3.8°–47.2° zoom from a 350 W engine.
Applications
ConcertFestivalsFilmLarge venuesLive eventsOutdoor / InstallTheatreTouringTV / Broadcast
Features
- Custom 350W Cold White LED Engine (6500K)
- 21,000 lumens through its 140 mm (5.5 in) front lens
- Its refined, center-peaked hotspot ensures crisp gobos, sharp mid-air effects, and consistent beam quality, even over long distances, ideal for arena side-keys, gobo projection, and precise aerial work
- 3.8°–47.2° linear zoom
- Its powerful effects engine includes CMY with linear CTO, dual gobo and animation wheels, prisms, iris, and 5°/1° frosts, while GoBright optimization maintains maximum brightness and color integrity
- Advanced Four-Focal-Planes Shutter System with independently adjustable blades, delivering precise beam shaping, smooth transitions, and the dramatic Total Curtain effect
Specifications
Power
350W
Source type
Cold White LED
Color temperature
6500 K ± 300K
CRI
Up to 70 with selectable filter for CRI up to 88
Zoom range
3.8° - 47.2°
Lumen
21.000 Lm (integrating sphere)
Protocols
DMX, Art-Net, sACN, RDM
Power con
PowerCon True1 IN/OUT
Colour mixing
Linear CMY/CTO
Colour Wheel
1 color wheel with 6 dichroic colors, tint channel
Framing Systems
4 blades (± 35° inclination) with ± 60° rotation of the full system
Gobos
1 static gobo wheel with 9 dichroic fixed interchangeable gobos • 1 rotating gobo wheel with 7 interchangeable glass gobos
